Wall Hung WC Frame (Excluding Cistern)

A wall hung WC frame excluding cistern is a robust support system designed specifically for wall-mounted toilet installations where the cistern is supplied separately. Ideal for bespoke bathroom layouts, it provides flexibility in positioning the cistern independently from the frame.

Constructed from heavy-duty steel, the frame securely supports a wall-hung WC pan while allowing pipework and flushing components to be concealed within a wall or furniture unit. This creates a clean, modern appearance while maintaining structural strength and reliability.

Key Features

• Designed for wall-hung WC pans (cistern not included)
• Compatible with separate concealed cistern systems
• Heavy-duty steel frame for high load capacity
• Ideal for custom or space-restricted installations
• Height adjustable for flexible positioning
• Suitable for in-wall, stud wall, or pre-wall installation
• Provides a clean, floating WC appearance

Specifications

• Height: Approx. 800–1100mm (depending on model)
• Width: Approx. 350–500mm
• Depth: Approx. 120–200mm
• Material: Powder-Coated Steel
• Installation: In-wall / Stud Wall / Furniture Unit
• Compatibility: Wall Hung WC Pans & Separate Concealed Cisterns

Additional Information

Frames without integrated cisterns are commonly used in specialist installations where a concealed cistern is positioned remotely or already installed. This setup allows greater flexibility in bathroom design, particularly in complex layouts or renovation projects.

For example, “half frames” are specifically designed to support wall-hung pans while allowing a separate concealed cistern to be installed elsewhere, making them ideal for converting back-to-wall systems into wall-hung setups. :contentReference[oaicite:1]{index=1}

When paired with a suitable concealed cistern and flush plate, this type of frame provides a fully functional and visually streamlined wall-hung WC system.
